The TB Series revolutionises hunting equipment by seamlessly integrating precision and portability. Its magnesium alloy housing not only reduces weight but also enhances accuracy, making it over 20% lighter than comparable products. With it’s 400 x 300 @12μm sensor, 35mm lens and Full-HD AMOLED display boasting wider viewing angles and richer colours, the TB430 sets a new standard in relaxed hunting experiences.
Features:
- 12μm advanced thermal detector, NETD<25mK
- Full-HD 1920×1080 AMOLED display
- Magnesium alloy housing, compact design, light weight but powerful
- Detection range up to 1800m
- Two Standard 18650 batteries provides up to 12 hours of operation
- Double Side focus knob for easy operation
- Video recording including sound
- IP68, Shock resistance up to 1000G/ms
Specifications:
Sensor
Type: Uncooled VOx Infrared Detector, 8 to 14 μm
Resolution: 400×300@12μm
NETD: 25mK
Frame rate: 50Hz
Lens
Objective lens: 35mm, F1.0
Field of view: 7.8°×5.9°
FOV m @100m: 14×10
Magnification: 1x
Detection range: 1400m/yd
Display
Display type: 0.39’’ AMOLED 1920x1080
Eyepiece: Exit pupil distance 20mm; Zoom: 6.4x
Hardware
WIFI: 2.4G, 5G
Interface: USB Type-C (Power supply/USB2.0)
Others: Microphone, Bluetooth
System
Recording function: Photo/Video
Memory capacity: 32GB
Power
Battery type: 2 replaceable 18650 batteries
Operating time: 12 hours
Environmental
Operating temp.: -20 °C to 50 °C/ -4°F to +122°F
Shock: 1000 G at 1 ms half sine pulse (as per IEC60068-2-27)
Encapsulation: IP68
Physical
Weight(g/ oz): 425/ 14.99
Size(mm/ in): 128×79×79/ 5.04×3.11×3.11
Standard: A device, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card
Optional: 18650 battery, Bluetooth remote control, Cover ring adapter
Cover ring adapter
A: Weight 70 g, Compatible with 38/ 40/ 42/ 44/ 46 mm
B: Weight 80 g, Compatible with 48/ 50/ 52/ 54 mm
C: Weight 90 g, Compatible with 56/ 58/ 60/ 62/ 64 mm
